FC CONNECTORS

The FC/PC connector is one of the original 2.5mm ferrule technology designs.  Starting out as the FC connector (sometimes known as face contact), the FC/PC connector (PC is sometimes referred to as physical contact) is an improvement of the original design.  The radiused ferrule end face of the FC/PC connector allows the optical fibers to touch, thus eliminating the air gap that usually results with the original FC design.  With the optical fibers in contact the attenuation decreases and the amount of light reflected back (Return Loss) to the source also decreases.  A typical FC connector has a return loss of about -14 dB where an FC/PC connector will have a return loss of -30dB.  Using special polishing techniques an FC/PC connector can be made to have Super PC (-40 dB) or Ultra PC (-50 dB) return loss characteristics.

SINGLEMODE

FC Singlemode Connector

PART FERRULE/BODY/CABLE
PRICE
MANUFACTURER
95-200-10-
BP3W 		ceramic/composite/3mm
$7.10
Siecor

PART FERRULE/BODY/CABLE
PRICE
MANUFACTURER
8203 ceramic/composite/900um & 3mm
$12.30
3M

PART
FERRULE/BODY/CABLE
PRICE
MANUFACTURER
68301-101
ceramic/metal/3mm
$7.80
Thomas & Betts

PART
FERRULE/BODY/CABLE
PRICE
MANUFACTURER
732-0021-
001
ceramic/metal/3mm
$7.90
AFOP

PART
FERRULE/BODY/CABLE
PRICE
MANUFACTURER
SAP-8
ceramic/metal/900um & 3mm
$7.00
Seiko Instruments USA



MULTIMODE

FC Multimode Connector

PART
DESCRIPTION
PRICE
MANUFACTURER
68301-201
125u ceramic/metal/3mm
$4.70
Thomas & Betts
68301-202
140u ceramic/metal/3mm
$6.70
Thomas & Betts

PART
DESCRIPTION
PRICE
MANUFACTURER
732-0011-001
125u ceramic/metal/3mm
$6.60
AFOP



CONTACT US FOR ORDERING
