ZAPMASTER®
7/6 The ZapMaster 7/6 is a comprehensive 512 pin ESD, latch-up and socketed CDM test system. The system can be configured as a 512 or 'Dual-256' pin test system. The ZapMaster delivers clean repeatable waveforms to any pin or combination of pins via a fully automated switching matrix and is capable of testing multiple devices simultaneously. The ZapMaster will supply precise ESD stimuli to selected pin devices and perform failure analysis via a rapid curve trace and optional Vcc/Icc measurements before and after each zap or series of zaps. As zap levels are increased for each series of zaps, failures are detected through a number of user defined failure criteria. The resulting data is displayed, analyzed and stored. The 'Dual-256' sub-systems can be operated simultaneously, testing different devices or testing to different specifications, with the addition of a second PC. The ZapMaster performs ESD, latch-up and socketed CDM testing to a variety of standards and range of voltages. ESD Human Body Model (HBM) per MIL-STD-883D; 50V to 8kV Human Body Model (HBM) per ESD Association 5.1; 50V to 8kV (up to 256 pins only) Machine Model (MM) per EIA/J standards 25V - 2kV JEDEC Latch-up per JEDEC 17 Socketed Charged Device Model (CDM) The ZapMaster has a standard one-year warranty with extended warranty programs available. For additional product information, please download the ZAPMASTER brochure. For an in-depth product specification sheet, please visit our literature room or complete the KeyTek Contact Us. |
|||||||||||||||||
|
