PARAGONT The Paragon is a multi-capability ESD and Latch-up test system for testing advanced integrated circuits. The Paragon system allows users to test devices from 256 pins up to 1024 pins. With such a broad pin count range, users are given the opportunity to test both simple and complex components, such as system-on-chip devices, using one test system. The Paragon delivers consistent, precise ESD waveforms and the centrally located DUT board reduces the inherent inductance and capacitance on each pin to a minimum, which is essential for quality ESD performance. In addition, high-speed vectoring and fast clock speeds provide for rapid device preconditioning and functional verification necessary for testing dynamic devices. Each Paragon is user-configurable to meet a company's specific ESD and latch-up test requirements. The base Paragon system features 256 pins and can be increased at the customer's site in 128 pin increments for up to a total of 1024 pins. In addition, high-speed vectoring capabilities, test features and pulse sources can also be added on site. By providing on-site upgrade capabilities, users can decrease their total down time. Paragon's Windows95â -based application software is a user-friendly interface for device definition, vector maps and test plan generation. The Paragon performs ESD and latch-up testing to a variety of standards and range of voltages. Human Body Model (HBM) per ESD Assoc. 1-1998 JEDEC EIA/JESD22-A114 and MIL-STD 883D, 100V to 8kV Machine Model (MM) per ESD Assoc. proposed 5.2 200pF/0W , 100V to 2kV standard and JEDEC EIA/JESD22-A115 Latch-up per JEDEC's EIA/JESD 78 Method The Paragon has a standard one-year warranty with extended warranty programs available. For additional product information, please download the PARAGON brochure. For an in-depth product specification sheet, please visit our literature room or complete the KeyTek Contact Us Form. |
|||||||||||||||||
|
