CenSlide^® 2000

Urine Sediment Analysis System

CenSlide 2000; a unique closed system for performing fast, clean, safe and accurate microscopic urinalysis.

The CenSlide 2000 system is microprocessor controlled to automatically spin CenSlide tubes at a preset speed for one minute. At the end of the cycle, the urine sediment is distributed evenly across the viewing area for microscopic analysis.

The CenSlide Urinalysis System controls inherent variations in microscopic examination by standardizing urine sediment volume, centrifuge conditions and technique while significantly reducing total time for analysis.

The CenSlide 2000 system includes a remote universal power supply that works off single-phase electrical power from 100-240VAC 50/60 HZ and is CE marked.

Documentation and Literature

• Brochure
• Service Parts
• Accessories
• Correlation Study
• Operator Manual

Centrifuge Specifications

Speed/Force	1,350 rpm / 97 xg
Cycle Time	Less than 60 seconds
Capacity	6-place rotor
Accell Time	15 seconds to 95% of speed
Regulatory	UL Marked
Warranty	1 Year
Power	24VDC 1.7A (wall adapter incl.)
Dimensions	5.6" H x 11.4" W x 12.9" D
Specification subject to change without prior notice. StatSpin is a registered trademark of Iris Sample Processing, Inc.





Tube Specifications

Material	Clarified Polypropylene
Capacity	2 - 5 mL
Viewing Area	7.9 mm x 10.7 mm
Dimensions	110 cm x 21 cm




Ordering Information

2C-9000-22	CenSlide 2000 Centrifuge
2C-2000-012	CenSlide Tubes (with Caps, 5 mL, 120 / pack)
2C-2000-240	CenSlide Tubes ( 20 packs of 120 - 2400 / case)
2C-5600-001	CenSlide Tube Holder, holds tube in place on a microscope stage allowing easy viewing.
2C-3000-001	StakRak , transport, storage and filling station for CenSlide Tubes, accommodates up to 12 tubes.
2C-4940-001	Microscope Objective, short with long working distance. For use with American Optical microscopes.
2C-4950-001	Microscope Objective, long with short working distance fits non-American Optical microscopes.
